DN200 ASTM A790 2205 / 1.4462 Big Size Duplex Steel Pipe For Food Industry

Minimum Order Quantity :	negotiable	قیمت :	5000-9000USD/TON
Packaging Details :	Iron Case / Plywood Case	Delivery Time :	30 Days
Payment Terms :	T / T ; L / C	Supply Ability :	300 Tons / Month

Place of Origin:	CHINA	نام تجاری:	MTSCO
گواهی:	ISO 9001 & PED & AD2000	Model Number:	MTSCODSP33

اطلاعات تکمیلی
Material:	1.4410 / S32750 / 2507 / 1.4462 / S31803 / 2205 Etc	Type:	Seamless
Ends:	PE / BE	Standard:	ASTM A790 / SA790 ; ASTM A789 / SA789 ; ASTM A312 Etc
NDT:	Eddy Current Or Hydraulic Test	Delivery Condition:	Soft / Hard
برجسته کردن:	Duplex Stainless Steel Pipe,Seamless Duplex Pipe , Seamless Duplex Pipe

توضیحات محصول

DN200 ASTM A790 2205 / 1.4462 Big Size Duplex Steel Pipe For Food Industry

Duplex stainless steel that was developed to combat common corrosion problems encountered with the 300 series stainless steels . “ Duplex ” describes a family of stainless steels that are neither fully austenitic , like 304 stainless , nor purely ferritic , like 430 stainless . The advantage of a duplex structure is that it combines the favorable qualities of a ferritic alloy ( stress corrosion cracking resistance and high strength ) with those of an austenitic alloy ( ease of fabrication and corrosion resistance ) .

Use super duplex stainless steel pipes can improve corrosion resistance compared to other materials . And super duplex steel pipes have greater tensile and yield strength , good ductility and yield strength , good stress corrosion cracking resistance . Also can help clients reduce their purchase costs , but can gurantee the quality etc .

Material Grade	S32205 , S31803 , S32304 , S32750, F51 , F53 , 2205 , 2507 etc
Outer Diameter	10.3mm - 1219mm
Wall Thickness	1.24mm - 54.59mm
Length	as per customer’s requirement
Standard	ASTM A789 ; ASTM A790 ; EN 10216-5ect .

Chemical Composition
Grade	C	Si	Mn	P	S	Cr	Ni	Mo	N
	max	max	max	max	max
UNS S32750	0.03	0.8	1.2	0.03	0.015	24.0-26.0	6.0-8.0	3.0-5.0	0.24-0.32
UNS S31803	0.03	1	2	0.02	0.02	21.0-23.0	4.5-6.5	2.5-3.5	0.08-0.20
Physical Properties
Grade	Y.S.MPa min		T.S.Mpa min		Elongation %		Hardness HRC		/
UNS S32750	550		800		15		20		/
UNS S31803	450		620		25		20		/

DN200 ASTM A790 2205 / 1.4462 Big Size Duplex Steel Pipe For Food Industry 0

Industry & Advantage	Application	a) Petroleum
		b) Chemical industry
		c) Instrument
		d) Industrial transportation
		e) Mechanical structure industry
		f) Need high corrision ability pipe's industry, such as offshore industry etc
	Advantages	a) Superior surface finish,
		b) Better mechanical property
		c) More precise dimension
		d) Perfect inspection method and inspection equipment
Terms & Conditions	Price Item	FOB, CFR, CIF or as negotiation
	Payment	T/T, LC or as negotiation
	Delivery Time	30 working days after received your deposit (Normally according to the order quantity)
	Package	Iron case; woven bag or as per customer’s requirement
	Quality Requirement	Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality	Test	NTD(Ultrasonic test, Eddy Current test);
		Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test);
		Metal Test(Metallographic Analysis, Impact Test-High/low temperature);
		Chemical Analysis(Photoelectric Emission Spectroscopic)
Market	Main Market	Europe, Middle East, Southeast Asia, South America. etc

Welcome everyone who need this kind of pipes contact to me in free . Also MTSCO can produce stainless steel seamless pipes, bright annealed tubes, seamless coiled tubing etc . You go ahead one step , we can help you creat more profits than your mind .
